| Parameter category |
parameter |
| Vehicle size (length, width, height) |
13 meters * 2.55-3.0 * 1.15-2.2 (or customized according to requirements) |
| Vehicle weight |
5.8-8.5 tons (varies depending on the vehicle model) |
| Design load capacity |
40-80 tons (varies depending on the vehicle model) |
| Rated quality |
22.4-100 tons (varies depending on the vehicle model) |
| Number of axes |
3-5轴 |
| wheelbase |
998043200,+1310+1310 (or customized according to requirements) |
| Tire specifications |
Number of tires |
12-20 (customized according to requirements) |
| |
Tire model |
1200R-22., 235/75R-17.5245/75-19.5295/60-22.5 (customized according to requirements) |
| braking system |
Front and rear drum dual circuit hydraulic brake and pneumatic brake system, independent parking brake |
| Suspension system type |
Mechanics |
Front and rear longitudinal steel plate springs, Fuhua |
| |
Air suspension |
Cylinder type pneumatic shock absorber, Fuhua |
| Material of the main beam |
T700 high-strength steel |
| Main beam and longitudinal beam parameters |
Vertical board thickness |
6/8/10/12mm |
| |
height |
480-500mm |
| |
Thickness of upper wing plate |
10/12/14/16/18/20mm |
| |
Thickness of lower wing plate |
10/12/14/16/18/20/22mm |
| Leg type |
28T, JOST, single action or linkage |
| ABS,EBS system |
KORMEE，WABCO |
| Tractor fuel type |
diesel oil |
| Traction pin model |
90#，50#（JOST) |
| spray |
Rust prevention+polyurethane paint, powder coating electrophoresis, customized according to needs |
| Turn lock(THT) |
4-12 pieces |
